Enterprise-Grade Thermal Drone
4-in-1 Multisensor Imaging Platform
Thermal, zoom, laser rangefinder, and 4K wide camera in one rugged platform. 42-minute flight time, 9km transmission, military-grade obstacle avoidance.
4-in-1 camera system
One drone, every perspective
The EVO Max 4T integrates a 640×512 thermal camera, 160x hybrid zoom camera, 1200m laser rangefinder, and 4K wide camera—delivering comprehensive situational awareness for any mission.
42-minute flight time
Cover more ground per mission
With intelligent battery management and efficient aerodynamics, the EVO Max 4T delivers up to 42 minutes of flight time—maximizing productivity and reducing downtime.
360° obstacle avoidance
Military-grade sensing fusion
Six-direction obstacle avoidance combines millimeter-wave radar and visual sensors for all-weather, day/night collision prevention—even detecting thin power lines.
9km transmission range
SkyLink 2.0 technology
Autel's proprietary SkyLink 2.0 transmission delivers stable 9km range with automatic frequency hopping and triple-band support for interference-free operation.
Rugged all-weather design
IP43 rated for harsh conditions
Built for professional use with IP43 weather resistance, -20°C to 50°C operating temperature, and 12m/s wind resistance for reliable deployment in any environment.
Autel Explorer + SDK
Complete mission planning
Autel Explorer app provides intuitive mission planning, real-time data sharing, and cloud management. Full SDK available for custom integration and automation.
Technical specifications
Configuration data for mission planning, procurement, and integration.
| Parameter | Value |
|---|---|
| Aircraft Weight | 920 g (±5 g) |
| Max Flight Time | 42 min |
| Max Hover Time | 35 min |
| Max Wind Resistance | 12 m/s |
| Operating Temperature | -20°C to 50°C |
| Water Resistance | IP43 |
| Transmission Range | 9 km |
| Thermal Camera | 640 × 512 @ 30fps |
| Zoom Camera | 160× Hybrid Zoom |
| Laser Rangefinder | 1,200 m |
| Wide Camera | 4K @ 60fps |
| Obstacle Avoidance | 6-direction |
| Battery Capacity | 7,100 mAh |
| Charging Time | 90 min |
Common questions
640×512 thermal camera with <40 mK thermal sensitivity (NETD) for high-resolution thermal imaging.
Up to 1,200 meters with ±1m accuracy for precise target positioning.
160× hybrid zoom (16x optical + 10x digital) for detailed long-range inspection.
Up to 42 minutes flight time, 35 minutes hover. 90 min full charge with 100W charger.
Yes, IP43 rated, -20°C to 50°C operation, 12 m/s wind resistance with battery preheat.
6-direction obstacle avoidance with radar + visual fusion for all-weather collision prevention.
SkyLink 2.0 provides up to 9km range with triple-band frequency hopping.
Yes, comprehensive SDK available for custom integration and automated missions.
